Glass Edging Machines
Double-Sided Horizontal Pencil Edging Line
Horizontal edging line with pencil-edge profile, processing both edges simultaneously.
| Model | CT-8 |
|---|---|
| Category | Glass Edging Machines |
| Key feature | 4 + 4 spindle pencil edging |
| Min. glass size | 230 mm |
| Max. glass size | 2500 mm |
| Glass thickness | 3 – 16 mm |
| Control system | PLC controlled · Touch screen · Speed control |
| Mechanical squaring | Yes |
| Water tank | 1 pc |
| Processing | 4, 5, 6, 8, 10 mm glass with fixed 10 mm wheel |
| Dimensions (W × L × H) | 4000 × 2500 × 2300 mm |
| Weight | 2600 kg |
| Voltage / Frequency | 380 V · 50 Hz |
| Total installed power | 20 kW |
Product Description
The CT-8 double-sided horizontal pencil edging line grinds and polishes two opposite edges of the glass simultaneously in a pencil (rounded) edge profile. The glass travels horizontally through the line; it is designed for high-capacity production of mirrors, furniture glass and appliance glass.
Adjustable width allows different glass sizes to be processed without interruption. Double-sided operation halves labour and processing time compared with single-sided machines.
×
❮
❯
![]()
