Glass Edging Machines
Double-Sided Horizontal Flat Edging Line
High-capacity double-sided horizontal line for flat edge polishing.
| Model | CT-12 |
|---|---|
| Category | Glass Edging Machines |
| Key feature | 6 + 6 spindle flat edging |
| Min. glass size | 230 mm |
| Max. glass size | 2500 mm |
| Glass thickness | 3 – 16 mm |
| Control system | PLC controlled · Touch screen · Speed control |
| Mechanical squaring | Yes |
| Water tank | 1 pc |
| Dimensions (W × L × H) | 4000 × 2500 × 2300 mm |
| Weight | 2600 kg |
| Voltage / Frequency | 380 V · 50 Hz |
| Total installed power | 22 kW |
Product Description
The CT-12 double-sided horizontal flat edging line applies flat edging and polishing to two edges of the glass at the same time. Rough grinding, fine grinding and polishing stages are completed in a single pass, making it suitable for glass processing plants running serial production.
Horizontal feeding allows large glass sheets to be processed safely; the line can be installed together with cutting and washing machines to form a fully automatic glass processing line.
×
❮
❯
![]()
